Lowell 810-T72, 8 Inch 15 Watt Dual Cone Speaker with 25V/70V Transformer

Model 810-T72 is a dual cone 8-inch 15W driver with dual voltage (25V/70V) 5W transformer. It provides solid performance for paging and background music. The driver features a 10 oz. ceramic magnet, 3/4-inch hard fiber whizzer cone, 1-inch voice coil and 20-gauge steel frame with zinc-plated finish. Order grille and enclosure separately.

FEATURES:

• Driver: 8 in. 15W dual cone driver with 10 oz. ceramic magnet, hard fiber whizzer cone and 1 in. voice coil.
• Frame: 20-gauge stamped steel with zinc-plated finish.
• Mounting Bolt Circle: 7.625 in.
• Transformer: 25V/70V with taps at 0.25, .5, 1, 2, 5W
• Assembly Frequency Response: 51Hz-11.6kHz (6dB) and 50Hz- 20kHz (6.4dB)
• Assembly Mounting Depth: 2.84 in.
• Assembly Dispersion Angle: 95 degrees conical
• Assembly Average Sensitivity: 97.9dB
