Sale!

P6100 – SCOPE PROBE DUAL 100MHZ 1X/10X COMPENSATION 10-35PF

$14.97 $24.95

100MHz Oscilloscope Probes 2PackThese passive high impedance probes are designed and calibrated for use on any oscilloscope that has an input impedance of 1M and whose input capacity is within the compensation range.Note: The ground spring specified in the

Flash Sale Ongoing

00
Day
00
Hours
00
Mins
00
Secs
Event has ended

100MHz Oscilloscope Probes 2Pack

These passive high impedance probes are designed and calibrated for use on any oscilloscope that has an input impedance of 1M and whose input capacity is within the compensation range.
Note: The ground spring specified in the manual is not included it is included only for high voltage probes
Features:

Attenuation ratio: x1 and x10
Bandwidth: 6MHz (x1) and 100MHz (x10)
Input resistance: 1M (x1) and 10M (x10)
Input capacitance: 90pF (x1) and 18pF (x10)
Compensation range: 1035pF (x10)
Rise time: 58ns (x1) and 3.5ns (x10)
Working voltage: 300Vpp (x1) and 600Vpp (x10)
Operating temperature range: 14F to +122C (10C to +50C)
Length: 4 feet
